Introduction

All software should perform at a high level. That means going underneath the hood, locating areas of improvement, and fine tuning the machine. Hardware instructions, computer cycles, cache-accesses, and context switches; how much memory is being used or how long a process takes; these and more, are all things to observe when seeking insight into where and how to improve performance.

Currently, ruperf aims to achieve three things:

• Provide a well-documented, high-level, performance analysis tool that adds to the existing landscape by improving and expanding upon what current tools offer.

• Leverage the safety of Rust and and it’s module system for a secure and fine-grained approach to performance analysis.

• Explore Rust in the Linux Kernel. We would like to eventually lower the scope in which Rust is used to beneath the system call level, and experiment with it’s safety and performance features there.

Existing landscape

The current landscape of analyzing software performance has many tools. They all have different features, and work at various levels of the machine. These are some of the tools that inspired our project:

perf

perf is a profiler tool for linux-based systems that abstracts away CPU hardware differences in Linux performance measurements and presents a simple command-line interface.

VTune

VTune is a closed-source performance analysis tool provided by Intel. It identifies time-intensive functions, time spent on I/O, cache misses, branch mispredictions, and more.

Gprof

Gprof is for Unix applications, and uses instrumentation and sampling to track code execution time and locate program hot spots.

DHAT: dynamic heap analysis tool

Part of Valgrind, DHAT examines program use of heap allocation. It tracks allocated blocks, and inspects memory access. It also identifies process-lifetime leaks, excessive turnover, short-lived blocks, unused or underused allocations, and inefficiently laid-out blocks.

flamegraph

FlameGraph is a tool that provides a visual representation of profiled software. which makes it easier to understand where a program is spending it’s time.

Overview of ruperf

Each of these tools are powerful in their own context. Utilizing them together can provide even greater leverage for calibrating software. Expanding upon what current tools provide will further bridge the gap between problems in modern software performance and the tools we use to solve them.

While ruperf is still in the beginning stages of development, we believe a solid and novel foundation is there. stat and test currently mimic their perf counterparts, and our goals for expanding upon them further involve adding timer information. gui is an extremely useful sub-command that combines the aid of data-visualization with the ease of a CLI. These are the minimum features we’ve described in our MVP, and we are planning to add more.

Our goals for lowering the scope of Rust beneath the system call level are so that we may further explore it’s potential as a safe and high-performing systems language. As you can probably guess, some of us really love Rust, and there isn’t much performance-analysis related Rust stuff in the current scope of things. Our hope is that this project highlights the pros of using Rust in a context as sensitive as hardware performance counter information.

What’s in Development

Want to contribute? Interested in what we’re working on? Here are things we need done!

For how to contribute, see CONTRIBUTING.

• A safe wrapper for the mmap() Linux system call
• Extend ruperf stat capabilities
• Tests for ruperf test
• ruperf record
• ruperf report
• Adding support for timers
• New programs to profile
• Lowering the scope of Rust beneath the system call level
